192.168.1.1 is too short for SIMD

Suppose you want to parse 192.168.1.1 as a URL host. In Ada that string is not a domain name. It is an IPv4 address, and the WHATWG URL Standard has a whole parser for it.

A reasonable function might look as follows.

uint64_t parse_ipv4(std::string_view s) {
  const char* p = s.data();
  const char* end = p + s.size();
  uint32_t addr = 0;
  for (int i = 0; i < 4; ++i) {
    if (p == end || *p < '0' || *p > '9') {
      return fail;
    }
    uint32_t val = uint32_t(*p++ - '0');
    while (p < end && *p >= '0' && *p <= '9') {
      val = val * 10 + uint32_t(*p++ - '0');
      if (val > 255) {
        return fail;
      }
    }
    addr = (addr << 8) | val;
    if (i < 3) {
      if (p == end || *p != '.') {
        return fail;
      }
      ++p;
    }
  }
  return (p == end) ? addr : fail;
}

Four octets, a dot between them. Out of range or out of place returns fail. Consume the whole string and you get a packed uint32_t in host order, first octet in the high byte. 192.168.1.1 becomes 0xC0A80101.

This version also treats 01.2.3.4 as 1.2.3.4. WHATWG does not. A leading zero starts an octal number. I will come back to that.

0.0.0.0 is 7 bytes. 255.255.255.255 is 15. WHATWG also allows one trailing dot (1.2.3.4.). Ada’s fast path accepts that trailing dot, not a second one.

I generated 10,000 random addresses with each octet uniform in 0 to 255. Average length 13.3 bytes. Shortest 9, longest 15. A 128-bit register holds 16 bytes, so you are always leaving lanes unused.

In my last post the input was a megabyte and SIMD was the right tool. Here I am not sure the setup is cheaper than four short decimal conversions.

Daniel Lemire has a post on doing this with SIMD, and a follow-up that revisits it with AVX-512. Wojciech Muła has an article on the same problem. I care about the 12-byte case, and about still having a general parser for the weird forms.

Hex, octal, and 127.1

WHATWG IPv4 is not just ddd.ddd.ddd.ddd. Browsers also accept 127.1, 127.0.1, 0x7f.0.0.1, 0177.0.0.1, and 3232235777. Ada has to accept them too. That parser has to detect 0x, reject 08 as a bad octal, and shift the last part by 8, 16, or 24 bits depending on how many dots it saw.

glibc inet_pton is a different grammar. It wants a nul-terminated C string, writes an in_addr, and does not implement WHATWG. I use it as a baseline.

The common case is still 192.168.0.1 or 12.121.244.111. Four decimal numbers, no leading zeros, optional trailing dot. Everything else can fall through.

if (uint64_t ip = try_parse_ipv4_fast(s); ip < (1ull << 32)) {
  return ip;
}
return parse_ipv4_general(s);

Daniel uses the same split in the C# post . One rule the fast path must get right: a leading zero is not decimal. 01.2.3.4 is octal in WHATWG. If the first digit of a group is 0 and a second digit follows, we return fail and let the general parser decide. 0.0.0.0 is fine. The zero is the whole group.

Unroll the four octets

The obvious parser has a while inside the for. Each octet may be 1, 2, or 3 digits, and the inner loop branches on a value the CPU has just loaded. We know there are exactly four groups, and each group is at most three digits. We can write that down.

uint64_t parse_ipv4_unrolled(const char* p, const char* end) {
  uint32_t addr = 0;
  for (int i = 0; i < 4; ++i) {
    if (p == end || *p < '0' || *p > '9') {
      return fail;
    }
    uint32_t val = uint32_t(*p++ - '0');
    if (p < end && *p >= '0' && *p <= '9') {
      if (val == 0) {
        return fail;  // leading zero: not our problem
      }
      val = val * 10 + uint32_t(*p++ - '0');
      if (p < end && *p >= '0' && *p <= '9') {
        val = val * 10 + uint32_t(*p++ - '0');
        if (val > 255) {
          return fail;
        }
      }
    }
    addr = (addr << 8) | val;
    if (i < 3) {
      if (p == end || *p != '.') {
        return fail;
      }
      ++p;
    }
  }
  if (p == end) {
    return addr;
  }
  if (p + 1 == end && *p == '.') {
    return addr;  // WHATWG trailing dot
  }
  return fail;
}

Let’s walk through 192.168.1.1:

• First group: '1', then '9', then '2'. val becomes 192. Next byte is '.'. Shift 192 into the address.
• Second group: 168. Same shape.
• Third group: '1'. The next byte is '.', so we stop at one digit. No leading-zero check, because there is no second digit.
• Fourth group: '1'. p == end. Done.

10.0.0.1 is the same, with more one-digit groups. 01.2.3.4 hits val == 0 on the second digit of the first group and returns fail. The general parser then reads it as octal.

There is no inner while. Each extra digit is a predicted forward branch. This is the portable path in Ada, parse_ipv4_decimal_scalar in checkers-inl.h , and what we ship when the machine does not have AVX-512.

Can we do better?

A SWAR fold that loses

In the last post, a 256-byte table lost to a wraparound compare. I tried the same kind of trick here. Once you know a group is three digits, you can load them as a uint32_t, subtract '0' from each byte, reverse the digits so the ones place sits in the low byte, and fold with the weights 1, 10, 100. Those weights are the constant 0x0000640a01.

// "192" reversed is bytes 2, 9, 1, 0.
// 0x640a01 is the weights {1, 10, 100, 0}.
uint32_t fold(uint32_t ones_first) {
  return (ones_first & 0xff)
       + 10u * ((ones_first >> 8) & 0xff)
       + 100u * ((ones_first >> 16) & 0xff);
}

255 becomes the bytes 5, 5, 2, 0. That dword is 0x00020505. 256 becomes 6, 5, 2, 0, which is 0x00020506. The unsigned compare dword > 0x00020505 is the range check. We will use that layout again in a minute.

I wired this fold into the unrolled parser. It was twice as slow as multiplying by ten as you go. The load, the reverse, and the three-term add are extra work on a group that is already two or three bytes long. SWAR wants eight bytes in a register. An IPv4 octet is not eight bytes.

Keep the incremental * 10. The ones-first dword is still a good way to compare against 255. It is a bad way to convert a single octet in scalar code.

Why SSE2 pre-validation does not help

The first SIMD version I would write is not a parser. It is a pre-check. Load 16 bytes, ask whether every live byte is a digit or a dot, ask whether there are exactly three dots, then run the unrolled scalar parser.

uint64_t parse_ipv4_sse2(const char* padded16, const char* exact,
                         size_t len) {
  const __m128i v =
      _mm_loadu_si128(reinterpret_cast<const __m128i*>(padded16));
  const __m128i digits = _mm_sub_epi8(v, _mm_set1_epi8('0'));
  const __m128i is_digit = _mm_cmpeq_epi8(
      _mm_min_epu8(digits, _mm_set1_epi8(9)), digits);
  const __m128i is_dot = _mm_cmpeq_epi8(v, _mm_set1_epi8('.'));
  const int live = int((1u << len) - 1u);
  const int ok = _mm_movemask_epi8(_mm_or_si128(is_digit, is_dot));
  if ((ok & live) != live) {
    return fail;
  }
  const int dots = _mm_movemask_epi8(is_dot) & live;
  if (__builtin_popcount(unsigned(dots)) != 3) {
    return fail;
  }
  return parse_ipv4_unrolled(exact, exact + len);
}

padded16 is the annoying part. _mm_loadu_si128 reads 16 bytes. A 12-byte host in the middle of a URL is not 16 bytes long. Load past the end of the allocation and you have undefined behavior. On the last page of a buffer it can fault.

Daniel ran into this in 2023 . His sse_inet_aton always reads sixteen bytes. The input must be part of a larger string, or you must overallocate. Wojciech’s article has the same constraint.

You can pad. You can copy the host into a 16-byte stack buffer. You can prove the URL buffer has slack. All of those cost something. The unrolled scalar path reads exactly len bytes.

Even if you pad for free, the pre-check does not replace the parse. It adds a 16-byte load, three compares, a movemask, and a popcount in front of the function you were going to run anyway. On this machine that pair is a tie.

Wojciech’s actual insight is better than a pre-check. There are only 81 ways to place three dots in a 16-byte window, plus a virtual dot at the end. You build a mask of the dot positions, map that mask through a table, and get a pshufb pattern that lays the digits out for a SIMD convert. His earlier version stops after locating the dots and converts each group in scalar code. I ran both. The production SSE convert I timed is the one in simdzone .

Masked loads and vpcompressb

AVX-512 changes the setup cost. A masked load takes a 16-bit mask and reads only those bytes. If the host is 12 bytes long, you load 12 bytes. You do not read past the string. You do not pad. Daniel has a post on this, and the C# IPv4 parser uses it to pull UTF-16 characters without over-reading.

Once the bytes are in a register, VBMI2 gives you vpcompressb. That is the instruction that makes the 81-entry table unnecessary. You take the positions of the dots, compress them into a tight vector, and compute the digit shuffle from those positions. No lookup.

The Ada kernel is the table-free AVX-512 path from simdip (parse_ipv4_avx512vl_notab5). It lives in try_parse_ipv4_fast .

const uint32_t len_mask = _bzhi_u32(~0u, unsigned(len));
const __m128i v = _mm_mask_loadu_epi8(
    _mm_set1_epi8('.'), __mmask16(len_mask), data);

_bzhi_u32 keeps the low len bits. The masked load fills lanes outside the mask with '.'. A padding dot cannot look like a digit, and the first padding dot sits at index len. It is the virtual fourth delimiter.

Subtract '0' from every lane. Lanes that were digits become 0 to 9. A compare gives you a digit mask. Anything inside len that is neither a digit nor a dot is junk, and we fail.

const __mmask16 delim = _mm_cmpeq_epi8_mask(v, _mm_set1_epi8('.'));
const __m128i iota = _mm_setr_epi8(
    0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15);
const __m128i c = _mm_maskz_compress_epi8(delim, iota);

Take 192.168.1.1. The string is 11 bytes. The dots sit at 3, 7, and 9. The first padding dot sits at 11. After the compress, c begins {3, 7, 9, 11, ...}.

From each delimiter, walk backward one, two, and three bytes. That is the ones, tens, and hundreds digits. Broadcast each delimiter into four lanes and subtract {1, 2, 3, 4}:

const __m128i k_rep = _mm_setr_epi8(
    0, 0, 0, 0, 1, 1, 1, 1, 2, 2, 2, 2, 3, 3, 3, 3);
const __m128i qi = _mm_shuffle_epi8(c, k_rep);
const __m128i prev = _mm_shuffle_epi8(
    _mm_alignr_epi8(c, _mm_set1_epi8(-1), 15), k_rep);
const __m128i offr = _mm_setr_epi8(
    -1, -2, -3, -4, -1, -2, -3, -4,
    -1, -2, -3, -4, -1, -2, -3, -4);
const __m128i idx = _mm_max_epi8(_mm_add_epi8(qi, offr), prev);

qi is the end of each group, repeated four times: {3,3,3,3, 7,7,7,7, 9,9,9,9, 11,11,11,11}. prev is the start of each group: {-1,-1,-1,-1, 3,3,3,3, 7,7,7,7, 9,9,9,9}. The -1 is “before the first byte.”

qi + offr walks backward from the delimiter: ones, tens, hundreds, and an unused lane. max(..., prev) clamps that walk so a short group cannot steal a byte from the previous group. A missing tens or hundreds digit lands on prev, which is a dot, which we have already zeroed in the digit vector. pshufb of -1 is also zero.

For the first group of 192.168.1.1:

• ones: max(3 - 1, -1) = 2, the '2'
• tens: max(3 - 2, -1) = 1, the '9'
• hundreds: max(3 - 3, -1) = 0, the '1'

For the third group, the single '1' at index 8:

• ones: max(9 - 1, 7) = 8
• tens: max(9 - 2, 7) = 7, the previous dot, so zero
• hundreds: max(9 - 3, 7) = 7, zero again

One pshufb gathers all four groups. Each group is stored as ones | (tens << 8) | (hundreds << 16). 255 is the bytes 5, 5, 2, 0, the dword 0x00020505. 256 is 6, 5, 2, 0. 192 is 2, 9, 1, 0, the dword 0x00010902.

const __m128i lim = _mm_setr_epi8(
    5, 5, 2, 0, 5, 5, 2, 0, 5, 5, 2, 0, 5, 5, 2, 0);
const __mmask8 over = _mm_cmpgt_epu32_mask(padded, lim);

Four groups, four dwords, one compare. We range-check the digits before converting them. The two can run in parallel.

The convert itself is a 4-wide dot product of those bytes with 1, 10, 100, 0. Same fold as 0x640a01, four times, in one instruction. On Ice Lake and later that is vpdpbusd. Without VNNI it is pmaddubsw plus pmaddwd. Same answer.

const __m128i wts = _mm_setr_epi8(
    1, 10, 100, 0, 1, 10, 100, 0,
    1, 10, 100, 0, 1, 10, 100, 0);
const __m128i res = _mm_dpbusd_epi32(_mm_setzero_si128(), padded, wts);

A few more masks finish the validation. Exactly three live dots: popcnt(dots) ^ 3 is zero only then, and padding dots do not count. Each group is 1 to 3 digits, which is a gap check on the compressed positions. No leading zeros: a '0' at the start of a group, with a digit after it, is a fail. 0.0.0.0 has no digit after those zeros, so it passes.

If every mask is clean, we pack the four bytes and bswap into host order. If anything is off, including hex, octal, two-part addresses, or 256.0.0.1, we return fail and the general parser runs.

Numbers

I ran these on an Intel Xeon with GCC 13.3 (-O3 -march=native). The machine is 2.4 GHz and has AVX-512BW, VL, VBMI2, and VNNI. I generated 10,000 random dotted-decimal addresses and parsed the set 2,000 times. Every input is valid.

The 81-mask and Muła functions read 16 bytes. I zero-padded the corpus up front, so those numbers do not include a memcpy. The scalar paths and the AVX-512 path read exactly the live bytes.

inet_pton is doing more work than we need: a nul-terminated string, an in_addr write, and a grammar that is not WHATWG.

The naive loop is already twice inet_pton. Unrolling the digit counts shaves a little more. The SWAR fold loses to that unrolled loop by about 2x.

SSE2 in front of the unrolled loop is a tie. Sometimes it loses by a nanosecond, sometimes it matches. I would not take a 16-byte over-read for that.

Muła’s locate-then-scalar SSE is a small win over unrolled, when the pad is free. It still converts each group in scalar code. The convert, not the locate, is the expensive part.

The simdzone 81-mask parser is the real SIMD convert. On this machine it is the fastest happy-path function I ran, faster than the AVX-512 kernel. Not a surprise: the input is already 16-byte padded, every address is valid, the table lookup is branchless, and there is no masked-load tax. Do not line that 320 up against Daniel’s 2023 Ice Lake number . Different machine, different compiler, different padding contract.

AVX-512 is four times the unrolled scalar path, and it does not need the pad. That is why Ada ships it. A URL host is a slice of a larger string. I do not want to promise 16 readable bytes at the end of a buffer.

This sits under parse_host. Faster IPv4 helps when the host is IPv4. It does nothing for https://example.com/. A host that starts with a letter never reaches this function.

I also timed the miss path. On a corpus of only the unusual WHATWG forms (0x7f.0.0.1, 0177.0.0.1, 127.1, 01.2.3.4, a 32-bit decimal, and so on):

The fast path is cheap to fail. Running it before the general parser costs about a nanosecond on a corpus where every address misses. On a mixed set, 19 dotted-decimal addresses for every unusual one, AVX-512-then-general stays at 4.6 ns. The general parser alone is 22 ns, because it is now doing the common case the hard way.

Which one should you use?

It depends on the machine and on how much IPv4 you actually see.

1. Unrolled scalar as the default. Four groups, at most three digits each, leading zeros rejected. No over-read. No table. This is what Ada uses when AVX-512 VBMI2 is not available.
2. Do not put SSE2 or NEON in front of that loop to “pre-validate” a 7-16 byte host. You still have to parse, and you have now promised to read 16 bytes. On this machine that pair is a tie.
3. Do not SWAR-fold a three-digit octet. The ones-first dword is a compare trick, not a convert trick. Incremental * 10 won.
4. The 81-mask SSE tables if IPv4 is the whole program and you can overallocate. Daniel and Wojciech already wrote this. It was the fastest happy-path function on this Xeon. I would not rebuild it for a URL parser.
5. AVX-512 VBMI2 when you have it and IPv4 shows up in the profile. Masked load, compress the dots, dword-compare against 255. Keep the general parser for everything the kernel refuses.
6. Always keep the fallback. Hex, octal, and 127.1 are not worth teaching to a SIMD kernel. A trailing dot is not one of those cases. The fast path already accepts it.

Compilers will unroll a four-iteration loop. They will not invent a masked load, and they will not notice that 255 is the dword 5, 5, 2, 0.

So far every address was four decimal groups. Suppose you want a harder problem.

A harder problem: IPv6

IPv6 is the 128-bit form, written as eight hex groups with colons: 2001:db8::1. The :: may appear once and means “fill the rest with zeros.” You can also embed an IPv4 address at the end (::ffff:192.168.1.1). The string can be 2 bytes (::) or 39 (2001:0db8:0000:0000:0000:0000:0000:0001), or 45 if you write the embedded IPv4 in decimal.

This is a different shape. The dots in IPv4 tell you where every group starts. The colons in IPv6 do not, because of ::. A table of 81 masks does not exist here. You first have to decide whether the input is even plausible: how many colons, whether :: appears twice, whether a dot means an embedded IPv4.

Ada has an AVX-512 helper that only answers that question. One masked 512-bit load, a compare against : and ., a few popcounts. Impossible strings never reach the piece parser. Possible strings still go through the scalar walk.

bool ipv6_structure_plausible(const char* data, size_t len) {
  if (len < 2 || len > 45) {
    return false;
  }
  const __mmask64 live = __mmask64((1ULL << len) - 1ULL);
  const __m512i input =
      _mm512_maskz_loadu_epi8(live, data);
  const __mmask64 is_colon =
      _mm512_mask_cmpeq_epi8_mask(live, input, _mm512_set1_epi8(':'));
  const __mmask64 is_dot =
      _mm512_mask_cmpeq_epi8_mask(live, input, _mm512_set1_epi8('.'));
  const int colons = int(_mm_popcnt_u64(uint64_t(is_colon)));
  if (colons > 8) {
    return false;
  }
  const uint64_t doubles =
      uint64_t(is_colon) & (uint64_t(is_colon) << 1);
  if (doubles != 0 && (doubles & (doubles - 1)) != 0) {
    return false;  // more than one "::"
  }
  if (doubles == 0 && is_dot == 0 && colons != 7) {
    return false;
  }
  return true;
}

doubles is the colon mask AND-shifted onto itself. Adjacent colons light a bit. If more than one bit is set, you have two :: (or :::), and the string is impossible. A full form without :: and without an embedded IPv4 must have exactly seven colons. Everything else, including ::1 and ::ffff:192.168.1.1, is plausible and goes to the scalar piece parser.

On a mix of valid addresses, two-:: junk, an over-long form, and a domain name, the scalar scan is about 10 ns. The masked load is about 1.4 ns.

Daniel has a post on a full AVX-512 convert (Shreesh Adiga’s kernel): one 512-bit load, expand on the colons, permute the hex. He gets about 70 million addresses per second on an Emerald Rapids Xeon, against inet_pton. That is a different job. In a URL parser the common host is still a domain name, and the cheapest parse is the one you do not run. In Ada, a host that starts with a letter never calls either IP parser.
