Eliminating branches in C++ loops

Suppose you want to check whether a string is made entirely of ASCII lowercase letters. It is a common check in parsers. In Ada we do this kind of classification constantly for URL characters: is this a hex digit, an unreserved character, a forbidden host code point?

A reasonable function might look as follows.

bool is_ascii_lowercase(std::string_view input) {
  for (unsigned char c : input) {
    if (c < 'a' || c > 'z') {
      return false;
    }
  }
  return true;
}

If any byte falls outside a-z, we return false. If the loop finishes, we return true. Importantly, this function exits as soon as a bad character is found.

If we expect that almost every input is valid, that early return can be expensive. The CPU guesses which side of the if will run. When it guesses wrong, you pay a pipeline flush. || and && make it worse because they short-circuit: the second compare is itself a branch.

Daniel Lemire has a post on a similar problem: checking whether a JSON string needs escaping. The structure is the same. A loop, a branch, return true at the end. The rest of this post follows the same ladder he uses there: scan the whole string, replace the compare with a table, then do eight or sixteen bytes at once.

Always cast the byte to unsigned char (or uint8_t) before you classify it. A plain char may be signed, and a signed value above 127 can become a negative index or break the range check.

Scan the whole string

If we expect that no bad character will be found, we can always scan the whole input. That lets the compiler try other optimizations. In particular, it is more likely to autovectorize the loop: to compile it using SIMD instructions on its own. Daniel calls this version branchless, because it does not branch out of the loop.

bool is_ascii_lowercase(std::string_view input) {
  bool ok = true;
  for (unsigned char c : input) {
    ok &= (c >= 'a') & (c <= 'z');
  }
  return ok;
}

& is not &&. Bitwise AND always evaluates both sides, so there is no short-circuit branch. The loop body is load, compare, compare, and, store. After the last byte we return the flag.

I prefer the dual form when I am looking for problems rather than confirming that everything is valid. Accumulate errors with OR:

bool is_ascii_lowercase(std::string_view input) {
  unsigned errors = 0;
  for (unsigned char c : input) {
    errors |= static_cast<unsigned>(c < 'a');
    errors |= static_cast<unsigned>(c > 'z');
  }
  return errors == 0;
}

On x86 those compares compile to setcc. That is a flag write, not a jump. The loop always runs to completion. That is what you want when the happy path is that the whole string is fine, and it is what the vectorizer wants to see.

We still have two comparisons per byte. We can do better.

One compare: the wraparound test

A byte is an ASCII lowercase letter if and only if it sits in ['a', 'z']. Subtract 'a' and that statement becomes “the result fits in 0 to 25”.

static inline bool is_lower(unsigned char c) {
  return static_cast<unsigned char>(c - 'a') <= 25;
}

Let’s walk through a few values:

• 'a' - 'a' is 0, and 0 <= 25.
• 'z' - 'a' is 25, still in range.
• '`' - 'a' wraps to 255, and 255 <= 25 is false.
• '{' - 'a' is 26, just outside.
• 'A' - 'a' wraps well above 25, so uppercase is rejected.

Bytes below 'a' underflow modulo 256 and land in the high end of the unsigned char range, where they fail the same <= 25 test as bytes above 'z'. Two comparisons become one.

bool is_ascii_lowercase(std::string_view input) {
  unsigned errors = 0;
  for (unsigned char c : input) {
    errors |= static_cast<unsigned>(
        static_cast<unsigned char>(c - 'a') > 25);
  }
  return errors == 0;
}

The body is now subtract, compare, or. There is no if, no return in the middle, and no ||. For a single closed interval like a-z, this is usually as far as scalar code needs to go.

The wraparound test only works for one interval. Hex digits, unreserved URL characters, and forbidden host code points are unions of ranges and punctuation. Bitwise arithmetic gets ugly there. A table does not.

A 256-byte lookup table

A simple way to classify a byte is to generate a 256-element array and look the value up. Daniel calls this memoization (and not memorization). You will sometimes hear “a table of size 255”. The last valid index of an 8-bit value is 255, but the length of the array is 256. Byte values run from 0x00 through 0xFF inclusive. A table of 255 entries leaves 0xFF unmapped.

Using C++17, you can have the compiler build the array at compile time from a lambda:

static constexpr std::array<uint8_t, 256> kIsLower = []() {
  std::array<uint8_t, 256> table{};
  for (unsigned c = 'a'; c <= 'z'; ++c) {
    table[c] = 1;
  }
  return table;
}();

bool is_ascii_lowercase(std::string_view input) {
  uint8_t ok = 1;
  for (unsigned char c : input) {
    ok &= kIsLower[c];
  }
  return ok != 0;
}

table{} zero-initializes every slot. The loop turns on only 'a' through 'z'. Everything else stays 0. Each character is checked with a single load, plus an AND. This might compile down to a single lookup instruction.

I am using lowercase here so the skeleton is easy to see. I would not ship a table for a-z. The wraparound test is already one subtract and one compare. A table replaces that with a load, and the load is slower. The table starts to win when the check is no longer a single interval.

Hex is the example I actually use this for. Two ranges plus a gap:

static constexpr std::array<uint8_t, 256> kIsHex = []() {
  std::array<uint8_t, 256> table{};
  for (unsigned c = '0'; c <= '9'; ++c) table[c] = 1;
  for (unsigned c = 'a'; c <= 'f'; ++c) table[c] = 1;
  for (unsigned c = 'A'; c <= 'F'; ++c) table[c] = 1;
  return table;
}();

bool is_ascii_hex(std::string_view input) {
  uint8_t ok = 1;
  for (unsigned char c : input) {
    ok &= kIsHex[c];
  }
  return ok != 0;
}

The scalar version of that check is (c >= '0' && c <= '9') || (c >= 'a' && c <= 'f') || (c >= 'A' && c <= 'F'). Six comparisons and a tree of short-circuit branches, or one load.

This is how Ada classifies URL characters. Daniel’s compile-time table post uses the same idea for forbidden host code points: '\0', tab, space, #, /, :, and so on. Those are not a single interval. They are a pile of allowed and forbidden bytes. A 256-byte table per class is cheaper than explaining those rules to the branch predictor.

Two caveats:

• Index the table with uint8_t or unsigned char. A signed char of 0xFF becomes -1 and walks off the front of the array.
• A table only wins if it stays in cache. 256 bytes is four cache lines. Rebuilding the table on every call is extra work, not a table.

I will come back to this with numbers. The short version is that a table is the right tool for hex or forbidden host bytes, and the wrong tool for a-z. A range is already one subtract and one compare. A table turns that into a load, and loads have latency.

Can we do better?

SWAR when SIMD is not available

If you do not have SIMD, or you do not want a runtime ISA dispatch, you can still process eight bytes at a time. The technique is called SWAR: SIMD within a register. Lamport described it in 1975 . The intuition is that modern computers have 64-bit registers. Processing eight consecutive bytes as eight distinct words is inefficient given how wide our registers are.

The first step is to load eight characters into a uint64_t. In C++, you might do it this way:

uint64_t word;
std::memcpy(&word, chars, 8);

It looks maybe expensive, but most compilers will translate the memcpy into a single load when optimizations are on.

We then treat that register as a vector of eight bytes and use ordinary integer arithmetic on all of them at once. Daniel’s SWAR posts are the best explanation I know. The building block is to repeat a constant across every lane:

constexpr uint64_t kOnes = 0x0101010101010101ULL;
constexpr uint64_t kHigh = 0x8080808080808080ULL;

constexpr uint64_t splat(uint8_t x) {
  return kOnes * x;
}

splat('a') is 0x6161616161616161. kHigh is a mask of the top bit of every byte. That high bit is our per-lane boolean. 0x80 means this byte failed. 0x00 means it did not.

If you have 8 bytes in a 64-bit word x, computing x - splat(32) subtracts 32 from each byte. It works well if each byte is greater than or equal to 32. Otherwise the operation overflows: if the least significant byte is too small, its most significant bit is set, and you cannot rely on the other lanes. That is why we first keep only ASCII bytes (x & kHigh is zero when every byte is below 128), and then apply both bounds.

// High bit set in each byte of x that is strictly less than n.
// Requires n <= 128.
constexpr uint64_t bytes_less_than(uint64_t x, uint8_t n) {
  return (x - splat(n)) & ~x & kHigh;
}

// High bit set in each byte of x that is strictly greater than n.
// Requires n < 128.
constexpr uint64_t bytes_greater_than(uint64_t x, uint8_t n) {
  return ((x + splat(127 - n)) | x) & kHigh;
}

bool eight_bytes_are_lowercase(uint64_t word) {
  const uint64_t non_ascii = word & kHigh;
  const uint64_t too_small = bytes_less_than(word, 'a');
  const uint64_t too_large = bytes_greater_than(word, 'z');
  return (non_ascii | too_small | too_large) == 0;
}

bytes_less_than subtracts n from each byte. A lane that was already below n underflows, and the & ~x & kHigh filter keeps only those underflows. bytes_greater_than adds 127 - n. A lane above n crosses 127 and lights the high bit.

If word is eight lowercase letters, the three masks are zero. If one lane is 'A' or '{' or 0xC3, the corresponding high bit in the OR is set.

The string-level version ORs the failure masks into an accumulator and finishes the leftover bytes with the scalar wraparound test. That’s slightly more than one operation per input byte in the main loop, which is the same claim Daniel makes for his JSON-escapable SWAR check.

bool is_ascii_lowercase(std::string_view input) {
  const auto* p = reinterpret_cast<const unsigned char*>(input.data());
  size_t n = input.size();
  uint64_t bad = 0;

  while (n >= 8) {
    uint64_t word;
    std::memcpy(&word, p, sizeof(word));
    bad |= word & kHigh;
    bad |= bytes_less_than(word, 'a');
    bad |= bytes_greater_than(word, 'z');
    p += 8;
    n -= 8;
  }

  while (n--) {
    bad |= static_cast<uint64_t>(
        static_cast<unsigned char>(*p++ - 'a') > 25);
  }

  return bad == 0;
}

The inner loop never branches on a character value. It always consumes eight bytes, always updates bad, and always continues. The leftover n < 8 bytes are not worth the SWAR setup.

SWAR is also a good way to understand the SIMD code. NEON is the same algorithm with 16-byte registers and real compare instructions.

The same check with NEON

ARM NEON can process 16 bytes at a time. One load, one compare, one OR. There is no SWAR carry trick, because the hardware already knows the lanes are independent. For the most part, your computer is either an ARM machine supporting at least NEON, or an x64 machine supporting at least SSE2. It is easy to distinguish at compile time.

A good general strategy, which Daniel uses in the escaping post , is to load the data in blocks of 16 bytes and do a few comparisons over those 16 bytes. What about fewer than 16 characters? If you do not want to read past the string, fall back on one of the conventional functions. If the leftover is non-empty but the string was already at least 16 bytes, you can reload the last 16 bytes of the input. That overlapping load avoids a scalar tail.

The first NEON version I wrote used two compares, an AND, and a NOT: vcgeq against 'a', vcleq against 'z'. That works. It is also more work than we need. The wraparound test is faster here too. Unsigned subtract wraps the same way in every lane, so we get c - 'a' for 16 bytes at once, then one unsigned compare against 25.

#include <arm_neon.h>

bool is_ascii_lowercase(std::string_view input) {
  if (input.size() < 16) {
    unsigned errors = 0;
    for (unsigned char c : input) {
      errors |= static_cast<unsigned>(
          static_cast<unsigned char>(c - 'a') > 25);
    }
    return errors == 0;
  }

  const auto* p = reinterpret_cast<const uint8_t*>(input.data());
  size_t n = input.size();
  uint8x16_t errors = vdupq_n_u8(0);
  const uint8x16_t va = vdupq_n_u8('a');
  const uint8x16_t limit = vdupq_n_u8(25);

  size_t i = 0;
  for (; i + 15 < n; i += 16) {
    const uint8x16_t v = vld1q_u8(p + i);
    const uint8x16_t d = vsubq_u8(v, va);
    errors = vorrq_u8(errors, vcgtq_u8(d, limit));
  }
  if (i < n) {
    const uint8x16_t v = vld1q_u8(p + n - 16);
    const uint8x16_t d = vsubq_u8(v, va);
    errors = vorrq_u8(errors, vcgtq_u8(d, limit));
  }

  return vmaxvq_u8(errors) == 0;
}

That is load, subtract, compare, OR. The two-bound version was load, compare, compare, AND, NOT, OR. Same answer, fewer instructions.

Here is what each intrinsic is doing:

• vdupq_n_u8('a') is the NEON splat. Every lane holds 'a'.
• vld1q_u8 loads 16 consecutive bytes. The instruction accepts unaligned addresses, so you do not need memcpy.
• vsubq_u8 subtracts 'a' from every lane. Bytes below 'a' wrap, exactly like unsigned char(c - 'a').
• vcgtq_u8 is an unsigned greater-than. A lane becomes 0xFF when that wrapped value is greater than 25.
• vorrq_u8 into errors is the same OR-accumulation as before.
• vmaxvq_u8 (AArch64) reduces the vector. If any lane is non-zero, some byte was out of range.

If the leftover is non-empty but the string was already at least 16 bytes, we reload the last 16 bytes. That overlapping load avoids a scalar tail. Duplicate bytes are fine: we only OR errors.

On x64 the same wraparound is subtract plus saturating unsigned subtract. _mm_subs_epu8(d, 25) becomes zero when d <= 25, and non-zero otherwise. Signed SIMD compares (_mm_cmplt_epi8) are a trap for bytes above 127, because those bytes look negative. The wraparound path stays unsigned the whole way.

bool is_ascii_lowercase(std::string_view input) {
  if (input.size() < 32) {
    unsigned errors = 0;
    for (unsigned char c : input) {
      errors |= static_cast<unsigned>(
          static_cast<unsigned char>(c - 'a') > 25);
    }
    return errors == 0;
  }

  const auto* p = reinterpret_cast<const uint8_t*>(input.data());
  size_t n = input.size();
  __m256i errors = _mm256_setzero_si256();
  const __m256i va = _mm256_set1_epi8('a');
  const __m256i limit = _mm256_set1_epi8(25);

  size_t i = 0;
  for (; i + 31 < n; i += 32) {
    const __m256i v =
        _mm256_loadu_si256(reinterpret_cast<const __m256i*>(p + i));
    const __m256i d = _mm256_sub_epi8(v, va);
    errors = _mm256_or_si256(errors, _mm256_subs_epu8(d, limit));
  }
  if (i < n) {
    const __m256i v =
        _mm256_loadu_si256(reinterpret_cast<const __m256i*>(p + n - 32));
    const __m256i d = _mm256_sub_epi8(v, va);
    errors = _mm256_or_si256(errors, _mm256_subs_epu8(d, limit));
  }

  return _mm256_testz_si256(errors, errors) != 0;
}

I ran these on an Intel Xeon with GCC 13.3 (-O3 -march=native), scanning a 1 MiB all-lowercase buffer. The happy path is the interesting one: you almost always scan the whole string.

The table loses to the naive loop. It is bound by load latency, which is the same thing Daniel saw when he compared a 256-byte identifier table to NEON. GCC already turns the scalar wraparound loop into SIMD, and that is 3.5 times the branchy version, but the hand-written SWAR and AVX2 paths still win by a lot.

If the first bad byte is near the start, the branchy loop wins, and the GB/s number becomes meaningless because you barely touch the buffer. That is the only case where I would keep the early return.

For messier classes, the 256-byte table fails in SIMD: there is no 256-byte gather on NEON. The usual trick is vectorized classification (see Langdale and Lemire, Parsing Gigabytes of JSON per Second ). We use the same idea in Ada. Split each byte into two 4-bit nibbles and look those up in two 16-byte tables:

uint8x16_t classify(uint8x16_t input,
                    uint8x16_t table_lo,
                    uint8x16_t table_hi) {
  const uint8x16_t lo = vandq_u8(input, vdupq_n_u8(0x0F));
  const uint8x16_t hi = vshrq_n_u8(input, 4);
  return vandq_u8(vqtbl1q_u8(table_lo, lo), vqtbl1q_u8(table_hi, hi));
}

vqtbl1q_u8 is a 16-entry table lookup done on all sixteen lanes at once. The low nibble picks a row, the high nibble picks a row, and the AND is 1 only when both halves of the original 256-entry table would have said yes. The table now lives in registers and you classify 16 bytes per call.

On x86 the same ideas map to SSE/AVX (_mm_cmpeq_epi8, _mm_shuffle_epi8). The NEON names change. The loop shape does not.

Which one should you use?

It depends on the check and on the length of the input. For a single interval like a-z, the numbers above are the whole story.

1. Early return false when invalid input is common and usually fails in the first few bytes. That is the only case where the obvious loop is the fast one.
2. Wraparound (unsigned char(c - 'a') <= 25) for a single interval. Write it as a branchless scalar loop first. GCC and LLVM will often autovectorize it. If that is already off the profile, stop.
3. SWAR or SIMD wraparound when the strings are long and you still see the scan in a profile. Prefer subtract-and-compare over two bounds. AVX2 or NEON will beat a portable SWAR loop when you have them. SWAR is the right fallback when you do not.
4. A 256-byte table when the check is a union of ranges or a mix of punctuation: hex, unreserved, forbidden host bytes. Size it at 256, not 255. Do not use a table for a-z. You are paying a load for a subtract.
5. Nibble tables in NEON/SSSE3 when that messy class is also the hot SIMD path. That is vectorized classification, the same idea we use in Ada.

You can still go further. Unrolling the NEON or AVX2 loop to 32 or 64 bytes hides some of the reduction latency. If invalid input is common but not always at byte 0, check the accumulator every few vectors and return early. On newer ARM, SVE2 match / nmatch can replace a pile of equality tests for small character sets. I would not start there.

Compilers will not invent a 256-byte character class for you, and they will not write the SWAR masks. Measure the version you are about to delete.

I used “is this string ASCII lowercase?” as the running example because the check is small enough to see every transformation. In practice, the checks I care about are the other ones: hex, unreserved, forbidden host bytes, whitespace. Those are the loops that show up in a URL parser, and they are often where a simple for loop with an early return becomes the bottleneck.

So far every byte stood on its own. Suppose you want a harder problem.

A harder problem: is this valid UTF-16?

Modern-day text in software can be expected to be Unicode. Unicode is stored in two formats: UTF-8 and UTF-16.

UTF-16 is used by several platforms to represent Unicode characters. Microsoft Windows uses it for file names and registry keys. Java and JavaScript use it for strings.

UTF-16 represents each character by one or two 16-bit code units. For characters in the Basic Multilingual Plane, which includes most commonly used characters from around the world, a single 16-bit unit suffices. For characters beyond this plane, UTF-16 uses a pair of 16-bit units known as a surrogate pair. That is how it covers a bit more than a million code points while keeping most characters in 16 bits.

Values making up surrogate pairs are either high surrogates (U+D800 to U+DBFF) or low surrogates (U+DC00 to U+DFFF). A pair is always made of a high surrogate followed by a low surrogate. Otherwise, we have an error.

Daniel has a post on putting a replacement character (U+FFFD) wherever that rule breaks. simdutf is the production version, and it is what V8 uses for String.toWellFormed. I only need the boolean: is this valid UTF-16?

A basic C++ function might look as follows.

bool is_high_surrogate(char16_t c) {
  return (c >= 0xD800 && c <= 0xDBFF);
}

bool is_low_surrogate(char16_t c) {
  return (c >= 0xDC00 && c <= 0xDFFF);
}

bool is_valid_utf16(std::u16string_view input) {
  for (size_t i = 0; i < input.size(); ++i) {
    if (is_high_surrogate(input[i])) {
      if (i + 1 < input.size() && is_low_surrogate(input[i + 1])) {
        ++i;
      } else {
        return false;
      }
    } else if (is_low_surrogate(input[i])) {
      return false;
    }
  }
  return true;
}

The function scans a buffer of char16_t values. If a high surrogate is followed by a low surrogate, we skip both. If a high surrogate is not followed by a low surrogate, or if a low surrogate appears without a preceding high surrogate, we return false. If the loop finishes, we return true. The function should be reasonably efficient.

Most of our processors have instructions that process eight 16-bit words per register. Most mobile processors today are 64-bit ARM with NEON. And most UTF-16 text never leaves the BMP. I suspect that this is the typical case: there are relatively few surrogate pairs in most text.

If you do not have NEON, you can still ask whether four code units contain any surrogate at all. Mask each 16-bit lane of a uint64_t with 0xF800 and look for 0xD800. No match means those four units are valid BMP text and you can skip the pairing. That is the same SWAR trick as the lowercase scan, just on 16-bit lanes.

We can write a function targeting ARM NEON using intrinsic functions. These give us low-level access to NEON. There are comparable intrinsics for Intel/AMD, RISC-V, and so on.

The classification inside the loop is the wraparound test from earlier. Adding 0x2800 to a high surrogate wraps it into 0x0000 to 0x03FF. Adding 0x2400 does the same for a low surrogate.

bool is_valid_utf16_neon(std::u16string_view input) {
  const char16_t* buffer = input.data();
  const size_t length = input.size();
  const size_t vec_size = 8;
  size_t i = 0;

  if (length >= vec_size) {
    uint16x8_t previous_high_surrogate_mask = vdupq_n_u16(0);
    for (; i + vec_size <= length; i += vec_size) {
      const uint16x8_t vec = vld1q_u16(
          reinterpret_cast<const uint16_t*>(buffer + i));

      const uint16x8_t low_surrogate_mask = vcleq_u16(
          vaddq_u16(vec, vdupq_n_u16(0x2400)), vdupq_n_u16(0x03FF));
      const uint16x8_t high_surrogate_mask = vcleq_u16(
          vaddq_u16(vec, vdupq_n_u16(0x2800)), vdupq_n_u16(0x03FF));

      const uint16x8_t offset_high_surrogate_mask = vextq_u16(
          previous_high_surrogate_mask, high_surrogate_mask, 7);
      const uint16x8_t offset_low_surrogate_mask =
          (i + vec_size < length &&
           is_low_surrogate(buffer[i + vec_size]))
              ? vextq_u16(low_surrogate_mask, vdupq_n_u16(0xFFFF), 1)
              : vextq_u16(low_surrogate_mask, vdupq_n_u16(0), 1);

      const uint16x8_t low_not_preceded_by_high =
          vbicq_u16(low_surrogate_mask, offset_high_surrogate_mask);
      const uint16x8_t high_not_followed_by_low =
          vbicq_u16(high_surrogate_mask, offset_low_surrogate_mask);

      if (vmaxvq_u16(vorrq_u16(low_not_preceded_by_high,
                               high_not_followed_by_low)) != 0) {
        return false;
      }
      previous_high_surrogate_mask = high_surrogate_mask;
    }
  }

  if (i > 0 && is_high_surrogate(buffer[i - 1]) && i < length &&
      is_low_surrogate(buffer[i])) {
    ++i;
  }

  for (; i < length; ++i) {
    if (is_high_surrogate(buffer[i])) {
      if (i + 1 < length && is_low_surrogate(buffer[i + 1])) {
        ++i;
      } else {
        return false;
      }
    } else if (is_low_surrogate(buffer[i])) {
      return false;
    }
  }
  return true;
}

This function uses NEON to validate UTF-16 in chunks of eight code units. For each chunk it loads the data, builds a high surrogate mask and a low surrogate mask, shifts those masks to check for valid pairs across vector boundaries, and returns false on a lone high or a lone low. After as many full chunks as we can, the remaining units go through the scalar function. If the last vector unit was a high surrogate and the first tail unit is its low partner, we skip that low so the scalar loop does not treat it as unmatched.

Though reasonably efficient, I expect that it is possible to do much better than this function.

A reader of Daniel’s post proposed a faster alternative that uses the fact that ARM NEON has interleaved loads. When we load the data, we put the most significant bytes in one register and the least significant bytes in the other. The most significant bytes are sufficient to check for errors, so we can check 32 bytes of input by validating just one 16-byte register.

bool is_valid_utf16_neon_v2(std::u16string_view input) {
  const char16_t* buffer = input.data();
  const size_t length = input.size();
  const int high_vec = 1;
  const size_t vec_size = 32;
  size_t i = 0;

  if (length * 2 >= vec_size) {
    uint8x16_t previous_high_surrogate_mask = vdupq_n_u8(0);
    const uint8_t* buffer8 =
        reinterpret_cast<const uint8_t*>(buffer);
    for (; i + vec_size < length * 2; i += vec_size) {
      const uint8x16x2_t pair = vld2q_u8(buffer8 + i);
      const uint8x16_t vec = vshrq_n_u8(pair.val[high_vec], 2);

      const uint8x16_t low_surrogate_mask =
          vceqq_u8(vec, vdupq_n_u8(0x37));
      const uint8x16_t high_surrogate_mask =
          vceqq_u8(vec, vdupq_n_u8(0x36));

      const uint8x16_t offset_high_surrogate_mask = vextq_u8(
          previous_high_surrogate_mask, high_surrogate_mask, 15);
      const uint8_t next_char_type =
          buffer8[i + vec_size + high_vec] >> 2;
      const uint8x16_t offset_low_surrogate_mask = vextq_u8(
          low_surrogate_mask,
          vdupq_n_u8(next_char_type == 0x37 ? 0xFF : 0), 1);

      const uint8x16_t low_not_preceded_by_high =
          vbicq_u8(low_surrogate_mask, offset_high_surrogate_mask);
      const uint8x16_t high_not_followed_by_low =
          vbicq_u8(high_surrogate_mask, offset_low_surrogate_mask);

      if (vmaxvq_u8(vorrq_u8(low_not_preceded_by_high,
                             high_not_followed_by_low)) != 0) {
        return false;
      }
      previous_high_surrogate_mask = high_surrogate_mask;
    }
    i >>= 1;
  }

  if (i > 0 && is_high_surrogate(buffer[i - 1]) && i < length &&
      is_low_surrogate(buffer[i])) {
    ++i;
  }

  for (; i < length; ++i) {
    const uint16_t surrogate_type =
        static_cast<uint16_t>(buffer[i]) >> 10;
    if (surrogate_type == 0x36) {
      if (i + 1 < length && is_low_surrogate(buffer[i + 1])) {
        ++i;
      } else {
        return false;
      }
    } else if (surrogate_type == 0x37) {
      return false;
    }
  }
  return true;
}

0x36 is a high surrogate’s top six bits (0xD800 >> 10). 0x37 is a low surrogate (0xDC00 >> 10). The follow-up paper pushes the same idea to 64-unit blocks.

You can do even better if you assume that the input rarely contains invalid characters, or rarely contains surrogates at all. I am going to leave that as an exercise for the reader.

To benchmark these functions, Daniel used a single string made of 10 million space characters. It is the easiest case: no replacement and no surrogate pairs. I suspect that it also represents a typical case. Using LLVM 16 and an Apple M2, he got:

So the fast ARM NEON code is about 8 times faster than the conventional code. He was measuring the correction version. The boolean one is the same pairing, with a return false instead of a store of U+FFFD.
