A space is a bit in a 32-byte table

Suppose you want to percent-encode a query string. In Ada (opens in a new tab) the rules come from the WHATWG URL Standard (opens in a new tab) . A space becomes %20. A quotation mark becomes %22. Letters stay put.

A reasonable function might look as follows.

void percent_encode(std::string_view input, const uint8_t set[],
                    std::string& out) {
  for (unsigned char c : input) {
    if (set[c >> 3] & (1u << (c & 7))) {
      out.append(hex + c * 4, 3);
    } else {
      out += static_cast<char>(c);
    }
  }
}

set is 32 bytes, one bit per possible byte. Byte c lives in set[c >> 3], and the bit inside that byte is c & 7. The hex table holds 256 entries of "%XX\0", so hex + c * 4 is the three characters you append. Space is 0x20: index 4, bit 0. The standard keeps a different table for a query, a path, a fragment, and a username. In the query table that byte is 0x0D, which is space, ", and #. The bit is set, so the space is encoded.

In the last post (opens in a new tab) an IPv4 host was 7 to 16 bytes and never filled a SIMD register. A query is long enough. The trouble is the output. Base16 (opens in a new tab) turns every byte into two characters, so a vector load becomes two vector stores. Percent-encoding turns some bytes into three and copies the others. hello world!!!!! is 16 bytes and becomes hello%20world!!!!!, which is 18. There is no store of a fixed width.

Scanning a URL can stop at the first byte that is special. Encoding cannot. It has to remember every byte that needs %XX and keep going.

Look up the table you already have

pshufb indexes 16 lanes. The table is 32 bytes, so it occupies two registers: one for 0x00–0x7F, one for 0x80–0xFF. The index in a half is (b >> 3) & 0x0F. A second shuffle turns b & 7 into 1 << (b & 7). AND the two results. A non-zero lane needs %XX.

A scan can bake its lookup into the binary, because the characters it rejects never change. Percent-encoding is handed a different table for each part of the URL. Building a fresh lookup from that table on every call was slower (opens in a new tab) , so this path loads the 32 bytes it was given.

int percent_mask(__m128i word, const tables& t) {
  const __m128i idx = _mm_and_si128(_mm_srli_epi16(word, 3), t.mask_0f);
  const __m128i lo = _mm_shuffle_epi8(t.cs_lo, idx);
  const __m128i hi = _mm_shuffle_epi8(t.cs_hi, idx);
  const __m128i high_byte = _mm_cmpgt_epi8(t.zero, word);
  const __m128i cs_byte =
      _mm_or_si128(_mm_and_si128(hi, high_byte),
                   _mm_andnot_si128(high_byte, lo));
  const __m128i bits =
      _mm_shuffle_epi8(t.pow2, _mm_and_si128(word, t.mask_07));
  const __m128i hits = _mm_and_si128(cs_byte, bits);
  return _mm_movemask_epi8(_mm_cmpeq_epi8(hits, t.zero)) ^ 0xFFFF;
}

SSE has no byte shift, so the index is a 16-bit shift. The neighbor spills into bits 5–7 of the low byte, and the AND with 0x0F drops that spill. Bytes 0x80–0xFF are negative as signed int8, which is how the compare picks the high half. 128 in the bit table is the byte -128.

movemask sets a bit where a lane is 0xFF. The compare against zero is 0xFF on the clean lanes, so XOR with 0xFFFF leaves a bit set on every byte that must be encoded.

For hello world!!!!! the mask is 32, bit 5. Count the trailing zeros, append "hello", append "%20", append "world!!!!!".

The same walk handles a whole window. Two adjacent windows with empty masks are one 32-byte append. Anything shorter than 16 bytes goes back to the byte loop, so a vector load never reads past the end of the string. The IPv4 fast path had to promise those bytes, or use a masked load. Before the first window the output reserves three bytes per input byte, which is the longest expansion, so the walk does not reallocate.

The shuffle stops at the mask. Each set bit is still three scalar bytes from the hex table. Base16 uses pshufb to write the digits. This path uses it to decide which bytes become digits.

void encode_mask_window(const char* p, uint32_t mask, size_t width,
                        std::string& out) {
  size_t off = 0;
  while (mask != 0) {
    const int zero_run = std::countr_zero(mask);
    if (zero_run != 0) {
      out.append(p + off, static_cast<size_t>(zero_run));
    }
    off += static_cast<size_t>(zero_run);
    out.append(hex + static_cast<uint8_t>(p[off]) * 4, 3);
    ++off;
    mask >>= static_cast<unsigned>(zero_run + 1);
  }
  if (off < width) {
    out.append(p + off, width - off);
  }
}

I checked this against the byte loop for every byte value, on each table the standard defines, and with a space at each offset of a 64-byte string. The strings matched. The walk in Ada’s percent-encoder (opens in a new tab) is this idea.

What it costs

Intel Xeon at 2.4 GHz, g++ 13.3, -O3. The output buffer is reserved to three times the input and reused, so this is the encode. Median of seven runs. The SSSE3 column is the function above, including strings shorter than the 48-byte minimum Ada uses in the library.

The run-copy column is the byte loop’s test, except a clean span is one append. That is the obvious scalar improvement. I wanted to know how much of the SIMD gap was just “copy more than one byte.”

On the query, 1024 input bytes in 107 ns is 9.6 GB/s. The byte loop is 1.0 GB/s. Copying the clean spans gets you to 1.9 GB/s, and the shuffle is the rest: it finds the gap sixteen bytes at a time. That row is the friendly case, one hit and then a kilobyte of letters. At 48 bytes, three loads of 16, the same shape was 112 ns against 12 ns. A 47-byte string leaves 15 bytes on the byte loop and landed near 26 ns.

A space every 16 bytes is one hit per window: 1028 ns against 374 ns, about 2.8 times. Repeating user:name@host/path?q=1 under the rules for a username and password, 256 bytes, is 281 ns against 221 ns, about 1.3 times. Colon, at-sign, slash, and question mark all have to be escaped, and the gaps are too short for the run copy to matter.

A string of spaces has no gap. The shuffle classified every lane, and then every lane is still a scalar %XX. 1024 bytes take 1462 ns in the byte loop and 1601 ns here, about 0.70 GB/s against 0.64 GB/s. The output is 3072 bytes either way. Two bytes lose for the other reason: loading the table costs more than testing two bytes.

There is no 256-bit version. The fast path is SSSE3, sixteen bytes, on a Xeon that has AVX-512. In the base16 post, widening the register is where 6.4 GB/s became 11 GB/s.

Ada takes this path only for the tail that starts at the first byte the table marks, and only when that tail is at least 48 bytes. The longest example in the library’s own benchmark of this function is 46 bytes, so those examples stay on the byte loop.

The code that writes a query or a fragment is compiled apart from this vector path, and it stays on the byte loop. Putting the intrinsics in the same file slowed those writes even on strings that never needed them.

On ARM the same lookup is one instruction that can index all 32 bytes (vqtbl2q_u8). On RISC-V there is no 16-bit mask. The code finds the next byte that needs encoding, copies the clean prefix, and encodes that one byte. I did not time either. When every byte is a hit, the byte loop is still the right choice.

Turning the escapes back into bytes is a different job, and it stays one byte at a time. A run of ordinary characters is copied in one block. %XX folds into a single byte. In an HTML form, + is also a space. Internationalized domain names are another conversion, UTF-8 to Unicode scalars and back. That one can go through simdutf (opens in a new tab) , and only if you ask for it at build time. The default leaves it off. Neither one uses this table.
